Üç fazlı PV İnvertör Apollo (8~30kW)

Fotovoltaik Güç Apollo Serisi Apollo 8000-T1~Apollo 30K-T1 için Konut Üç Fazlı Şebeke Üstü Dize İnvertör

Üç fazlı PV İnvertör Apollo (8~30kW)

The DC capacitance ratio can reach as high as 1.5 times, which is perfectly suitable for high currentand double-sided solar panels.

DC arcing detection function can be selected to eliminate potential fire hazards.

The adaptive control algorithm adopted ensures the product fit for unstable grid.

Flexible monitoring modes support RS485, Wi-Fi and GPRS.

The product has IP66 degrees of protection and C5 anti-corrosion.

The product supports output of 1.1 times overload. This effectively increases power generation.

Paylaşmak için:

Açıklama

Teknik parametre:	Apollo 8000-T1	Apollo 10K-T1	Apollo 12K-T1	Apollo 15K-T1	Apollo 17K-T1	Apollo 20K-T1	Apollo 25K-T1	Apollo 30K-T1
	Input parameters (DC)
Maximum panel input power recommended (kW)	12	15	18	22.5	25.5	30	32.5	39
Maximum DC input voltage (V)	1100
Maximum input current of each MPPT (A)	16		20		26		32
Short circuit current of each MPPT (A)	25		25		39		50
Max.Power of each MPPT (kW)	9.6		12		15.6		19.5
No. of MPPT / strings	2/1		2/2		2/2		2/2+3
Start-up voltage (V)	180
MPPT Voltage range (V)	160V~1000
Full-load MPPT Voltage range (V)	550~850
Rated input voltage (V)	600
	Output parameters (AC)
Rated output power (kW)	8.8kW@40℃ 8kW@45℃	11kW@40℃ 10kW@45℃	13.2kW@40℃ 12kW@45℃	16.5kW@40℃ 15kW@45℃	18.7kW@40℃ 17kW@45℃	22kW@40℃ 20kW@45℃	27.5kW@40℃ 25kW@45℃	33kW@40℃ 30kW@45℃
Maximum apparent power (kVA)	8.8	11	13.2	16.5	18.7	22	27.5	33
Max.output power (kW)	8.8	11	13.2	16.5	18.7	22	27.5	33
Output connection type	3W+PE or 3W+N+PE
Rated voltage/Voltage range (V)	380/320~480
Nominal şebeke frekansı	45~55Hz / 55~ 65Hz (According to local grid standards)
Rated output current (A)	12.2	15.2	18.2	22.8	25.8	30.4	38.0	45.6
Maximum output current (A)	13.4	16.7	20.1	25.1	28.4	33.4	41.8	50.1
Power Factor (settable)	> 0.99 @ full power (adjustable range: 0.8 leading ~ 0.8 lagging)
Total Harmonic Distortion THDi (full load)	＜3% (full load)
MPPT verimliliği	Efficiency 99.9%
Maksimum verimlilik	98.4%		98.5%		98.6%		98.6%
Euro. efficiency	97.8%		98.0%		98.1%		98.2%
China efficencty	97.5%		97.8%		98.0%		98.0%
DC switch with Shunt release	Protection function Available
Output short circuit protection	Available
Power grid fault monitoring	Available
DC ters bağlantı koruması	Available
String monitoring	Available
DC lightning protection	type II
AC lightning protection	type II
DC insulation impedance detection	Available
AC leakage current detection	Available
Over-temperature protection	Available
DC component monitoring	Available
DC fuse	/
Islanding detection	Available
Smart IV diagnosis	Available
Arc fault detection	Optional
Bus voltage monitoring	Available
PID repair and protection	Optional
Low Voltage Ride Through	Available
Arc fault detection	Option
Remote upgrade and setup	Available
anti-counterflow meter	Available
Fault recorded	Available
Nighttime SVG features	Optional
Display mode	Görüntüleme ve iletişim LED+bluetooth+APP
Communication mode	RS485/4G/WIFI

	Genel parametreler
Dimension (mm)(W×H×D)	430×380×180
Weight (kg)	17	17
Operating temperature range	-30℃～+60℃ (＞45°Derating use)
Soğutma modu	Air colling without fan	Intelligent air cooling with Fan
Ürünün çalışması için maksimum irtifa	4000m (＞2000m Rating reduction occurs)
Relative Humidity	0~100%
Input terminal	MC4 (Amphenol)
Output terminal	OT/DT terminal(Max.50mm2 cable section)
Degree of protection	IP66
Self power consumption at night	<1W
Noise (dB)	<35	<40
Topoloji	no transformer
